Study on sea sand as a partial replacement for fine aggregate
DOI:
https://doi.org/10.24297/jac.v13i4.5661Keywords:
Fine aggregate, sea sand, minerals, concrete strengthAbstract
Sand researches around the world are in continuous search for the alternatives of sand. Fine aggregate is an important constituent of concrete and is required in large quantities. Generally, river sand is used as fine aggregate. Due to the increase in the utilization of concrete in construction sector, the need for river sand has been increased enormously. Hence, the abundant sea sand can be used as an alternative of river sand partially.The sea sand samples before (samples A and C) and after mineral extraction were utilized to replace for fine aggregate. The mineral extracted chiefly includes ilmenite, zircon, rutile, sillimanite and super garnet was confirmed by an analytical technique Energy-dispersive X-ray analysis (EDXA). Physical properties of these sands were recorded. Results reveal that the angle of internal friction (Ø) was high and low in sample A and C, but an opposite trend was observed for specific gravity. Except sample D, remaining samples belong to grade II size.  Concrete cubes were laid for M35 grade concrete with the combinations of the above samples. The fine aggregate proportion from the design mix was replaced partially by 20% of sea sand. Compressive strength test and pull out test and the behaviour of concrete were conducted on the various soil specimens and the results were tabulated. The strength tests were conducted at 7, 14 and 28 days of water curing. Compressed strength, band strength as well the weight kg-1of the concrete did not affected by replacement of either sample A (10%) or sample B (20%). Proposed replacement is economically cheaper. Considering laboratory studied, we recommended to utilized sea sand for partial replacement for fine aggregate.Â
Downloads
References
2. Al-Jabri, K. S., Hisada, M., Al-Oraimi, S. K., & Al-Saidy, A. H. (2009). Copper slag as sand replacement for high performance concrete. Cement and Concrete Composites, 31(7), 483-488.
3. Chandrakeerthy SRDeS. 1994. Suitability of sea sand as a fine aggregate for concrete production, Transactions, Institution of Engineers, Sri Lanka. 1994:93-114.
4. Chandrakeerthy, S.R.De S., 1994. Suitability of Sea Sand as a Fine Aggregate for Concrete Production. 01, P 93-114
5. Dolage, D. A. R., Dias, M. G. S. and C. T. Ariyawansa, “Offshore Sand as a Fine Aggregate for Concrete Productionâ€, British Journal of Applied Science & Technology, 3(4): 813-825, 2013.
6. Dolage, D. A. R., Dias, M. G. S. and C. T. Ariyawansa. 2013. Offshore Sand as a Fine Aggregate for Concrete Production. British Journal of Applied Science & Technology 3(4): 813-825.
7. Dong, Z., Wu, G., & Xu, Y. (2016). Experimental study on the bond durability between steel-FRP composite bars (SFCBs) and sea sand concrete in ocean environment. Construction and Building Materials, 115, 277-284.
8. Huang, H.X. 2007. An experimental study on the durability of sea sand concrete, Master thesis, Jinan University, Jinan, China (in Chinese).
9. Huiguang Y, Yan L, Henglin L, Quan G. 2011. Durability of sea sand containing concrete: Effects of chloride ion penetration. Mining Science and Technology (China),21:123-127.
10. IS 10262-2009 : Concrete mix proportioning – Guidelines
11. IS 2770 (Part 1) -1967 : Methods of testing bond in reinforced concrete (Pull-out test)
12. IS 383 (1970) : Specification for Coarse and Fine Aggregates from Natural - Sources for Concrete
13. Jiang, Y., Liu, J. Z., Sun, W., Zheng, C. Y., & Wu, S. Y. 2015. Study on the properties of sea sand concrete with Fly Ash. In Advanced Materials Research, 1065: 1854-1857.
14. Jianghong, M. A. O., Weiliang, J. I. N., Hua ZHANG, C. X., & Jin, X. I. A. (2016). Technology for Enhancing Durability of Structures of Sea-sand Concrete and Its Application. Journal of Chinese Society for Corrosion and protection, 35(6), 563-570.
15. Kumar, B. N. N., Kumar, P. K., Babu, E. R., Gopal, M., Reddy, D. S., Sreekanth, K., & Yellppa, U. 2016. An experimental study on sea sand by partial replacement of sea Sand in Concrete. IJSRST 2(2): 181-184.
16. Li, Y. L., Zhao, X. L., Singh, R. R., & Al-Saadi, S. (2016). Experimental study on seawater and sea sand concrete filled GFRP and stainless steel tubular stub columns. Thin-Walled Structures, 106, 390-406.
17. Limeira J, Etxeberria M, Agullo L, Molina D. 2011. Mechanical and durability properties of concrete made with dredged marine sand. Journal of Construction and Building Materials. 25:4165-4174.
18. Mithun, B. M., & Narasimhan, M. C. 2016. Performance of alkali activated slag concrete mixes incorporating copper slag as fine aggregate. Journal of Cleaner Production, 112, 837-844.
19. Mehta and Monteiro. 1993. Concrete Structure, Properties, and Materials, Prentice-Hall, Inc., Englewood Cliffs, NJ
20. Micelli, F., A. Nanni, 2004. Durability of FRP rods for concrete structures, Constr. Build. Mater. 18 (7) (2004) 491–503.
21. Newman K. 1968. Aspects of workability, strength, shrinkage and creep, sea dredged aggregates for concrete, Proceedings of a Symposium, Sand and Gravel Association of Great Britain, Buckinghamshire
22. Nong, R. 2008. The experimental study on mechanical properties of sea sand concrete components, Master thesis, Harbin Institute of Technology, Harbin, China (in Chinese).
23. Praveen Kumar P, Shareef NM, Gopalan CV. Marine sand resources in the south-west continental shelf of India. Indian Journal of Geo-Marine Sciences. 2010; 39(4):572–78.
24. Rafieizonooz, M., Mirza, J., Salim, M. R., Hussin, M. W., & Khankhaje, E. (2016). Investigation of coal bottom ash and fly ash in concrete as replacement for sand and cement. Construction and Building Materials, 116, 15-24.
25. Robert, M., B. Benmokrane, 2010. Effect of aging on bond of GFRP bars embedded in concrete, Cem. Concr. Compos. 32 (6) (2010) 461–467.
26. Singh, Malkit, and Rafat Siddique. 2016. Effect of coal bottom ash as partial replacement of sand on workability and strength properties of concrete. Journal of Cleaner Production 112: 620-630.
27. Sai Deepak, W. and G. Tirupathi Naidu. 2015. Effect on compressive strength of concrete using sea sand as a partial replacement for fine aggregate.International Journal of Research in Engineering and Technology 4(6): 180-183.
28. Satish Kumar, D., Manjunath, L.R., Nataraja, M.C., Marutiram Kaza and Prasad, S.M.R. 2016. Urgent need for a new aggregate standard. The Indian Concrete Journal pp. 65-72.
29. Subashini,B. and Sivaranjani, G., 2016. Experimental Investigation of Sea Sand for Construction Purposes. Indian Journal of Science and Technology, 9(11), DOI: 10.17485/ijst/2016/v9i11/89400
30. Sudha, C., Ravichandran, P. T., Krishnan, K. D., Rajkumar, P. K., & Anand, A. (2016). Study on Mechanical Properties of High Performance Concrete using M-Sand. Indian Journal of Science and Technology, 9(5). DOI: 10.17485/ijst/2016/v9i5/87262,
31. Subashini, B., G. Sivaranjani , G. Dhanalakshmi , K.Gayathri , A. Ashok Kumar , A. Srimathi and C. Revathi. 2016. Experimental Investigation of Sea Sand for Construction Purposes. Indian Journal of Science and Technology, 9(11), DOI: 10.17485/ijst/2016/v9i11/89400
32. Sukumaran PV, Unnikrishnan E, Gangadharan AV, Zaheer B, Abdulla NM, Kumaran K, Ramachandran KV, Hegde SV, Maran N, Bhat KK, Rao MK, Dinesh AC, Jayaprakash C, Zhiqiang Dong, Gang Wu and Yiqian Xu. 2016. Experimental study on the bond durability between steel-FRP composite bars (SFCBs) and sea sand concrete in ocean environment. Construction and Building Materials 115: 277–284.
