UNDERSTANDING THE LIGHTNING DISCHARGE WITHSTAND AND BREAKDOWN CHARACTERISTICS OF NANO SiO2 MODIFIED MINERAL OIL FOR TRANSFORMER APPLICATIONS

Abstract

The successful operation of electrical power system network depends on the performance of insulation provided in the high voltage power transformers. Recent output of many research works confirm that the nano modified insulation system provides enhanced dielectric and thermal characteristics when compared with conventional system. Now a days nano modified mineral oils are considered as an alternative to conventional mineral oils as a dielectric insulation fluid in power transformers, leading to the improved dielectric strength of apparatus with further reduction in the size and manufacturing cost. Since distribution transformers are mainly used in outdoor applications, understanding its lightning discharge withstand and breakdown characteristics of nano modified insulating fluid is a vital issue. In this paper laboratory experimental works are performed to understand the lightning discharge performance of mineral oil along with SiO₂ nanofiller at different %wt concentration such as 0.01%, 0.05% and 0.1%. Standard lightning impulse voltage of 1.2/50 µs time period with both positive and negative polarity is used in the experiments. Results illustrate that the nano modified mineral oil significantly improves the lightning impulse withstand and breakdown strength of insulation system.
